- 名称：瓦克wacker R406-70 ELASTOSIL固体硅胶
- 型号：R406-70
- 规格：
- 说明：瓦克R406-70是有机硅混炼胶，在加入硫化剂后通过加热硫化成型(硫化剂 根据工艺所需来选择)。可铂金
详细说明
ELASTOSIL R 406/70 CN
HCR SILICONE RUBBER
Characteristics
ELASTOSIL® R 406/70 CN is fume grade high
consistence silicone rubber for general purpose
application.
ELASTOSIL® R 406/70 CN could be cured by both
peroxide and Platinum catalyst system. Cured
articles are noted for the good flexibility and good
transparence and elasticity properties. The
compounds are easily pigmented with pigment
pastes and have a good processing characteristic.
The various grades can be blended in any
proportion to achieve intermediate hardness.
Application
Postcured parts can be used for applications in
the pharmaceutical and food industries and
comply with the recommendations “XV. Silicone”
of the BfR and FDA § 177.2600 under observance
of any given limitations on extractable and volatile
substances.
Processing
ELASTOSIL® R 406/70 CN is designed for both
press curing and extrusion application.
For detailed information, please refer to our
brochure "Processing ELASTOSIL® R Solid
Silicone Rubber".
Storage
The “Best use before end” date of each batch is
shown on the product label.
Storage beyond the date specified on the label
does not necessarily mean that the product is no
longer usable. In this case however, the properties
required for the intended use must be checked for
quality assurance reasons.
Safety information
Comprehensive instructions are given in the
corresponding Material Safety Data Sheets. They
are available on request from WACKER
subsidiaries or may be printed via WACKER web
site http://www.wacker.com.
ELASTOSIL® R 406/70 CN
Typical general characteristics
Inspection Method
Unit
Typical Value
Appearance Transparent
Specific gravity DIN EN ISO 1183-1 A [g/cm3 ] 1.19
Curing Agent E
Hardness Shore A DIN 53505 - A Shore A 70
Tensile strength DIN 53504 S1 N/mm2 10
Elongation at break DIN 53504 S1 % 350
Tear strength ASTM D 624 B N/mm 25
Rebound elasticity DIN 53512 % 50
Compression set DIN ISO 815-B
(22 h/175°C)
[%]
23
Curing Agent C6
Hardness Shore A DIN 53505 - A Shore A 72
Tensile strength DIN 53504 S1 N/mm2 10
Elongation at break DIN 53504 S1 % 420
Tear strength ASTM D 624 B N/mm 25
Rebound elasticity DIN 53512 % 50
Compression set DIN ISO 815-B
(22 h/175°C)
[%]
21
Platinum Catalyst R406/70CN : (AUX 4K-X) :(AUX 4K-I) : (AUX Batch PT1) = 100 : 5 : 2.5 : 1.5
Hardness Shore A DIN 53505 - A Shore A 72
Tensile strength DIN 53504 S1 N/mm2 9
Elongation at break DIN 53504 S1 % 480
Tear strength ASTM D 624 B N/mm 35
Rebound elasticity DIN 53512 % 52
Compression set DIN ISO 815-B
(22 h/175°C)
[%]
12
Cure conditions
Curing agent
%
Cure
Post-cure
E 50% paste of bis-(2,4-dichlorobenzoyl)- peroxide in
silicone fluid
1.5
10 min / 135 ℃ 4 h / 200 ℃
C1 Dicumyl peroxide (98%) 0.7
15 min / 165 ℃ 4 h / 200 ℃
C6 45% paste of 2,5-bis-(t-butylperoxy)-2,5-dimethyl
hexane in silicone rubber
1.2
15 min / 165 ℃ 4 h / 200 ℃
PT catalyst
ELASTOSIL® AUX 4K-X, AUX 4K-I, AUX Batch PT1
5 min / 165 ℃ 4 h / 200 ℃
Curing Agent C6 yields similar values to those obtained with C1.
These figures are only intended as a guide and should not be used in preparing specifications.
